AB-1R13-177
Description
Genuine Goodyear Air Springs - Rolling Lobe w/ Composite Piston
Alternate SKU
AB1DK25E-8708, AB1DK25E8708, 352-8708, 3528708, 452-8708, 4528708, AS-8526, AS8526, W01-358-8708, W013588708, 8708, 1R13-177, 1R13177, AB1R13177, 10 10-16 P 526, 101016P526, 64638, HT-S21966, HTS21966, S-21966, S21966
Weight (lb)
20.00
- Attribute Value
- Product Name AB-1R13-177
- Make Hendrickson
- Top Plate Bolt Hole Quantity 2
- Bottom Plate Bolt Hole Quantity 1
- Top Plate Diameter 10.3 in
- Bottom Plate Diameter 8.8 in
- Piston Material Plastic
- Minimum Height 9.1 in
- Maximum Height 19 in
- Top Plate Center To Center Diameter 5.5 in
- Bottom Plate Center To Center Diameter 0 in
- Bottom Plate Alignment Parallel
- Bracket No
- Bumper Yes
- Bellows Number 566-26-3-078
- Bellows Color Black
- Bellows Material Textile Reinforced Polymer Rubber
- Air Spring Type Rolling Lobe
- Company Sku
- Automann AB1DK25E-8708, 566.CT64638, 566.ER8708
- Continental 64638
- Continental Bellows 10 10-16
- Dayton 352-8708, 452-8708
- Firestone W01-358-8708
- Firestone Bellows 1T17CA6.5
- Flagg/Triangle AS-8526
- Flagg/Triangle Bellows 6382
- Goodyear 1R13-177
- Goodyear Bellows 566-26-3-078
- Infinity SR8708
