AB-1R13-118
Description
Genuine Goodyear Air Springs - Rolling Lobe w/ Composite Piston
Alternate SKU
AB1DK25C-9580, AB1DK25C9580, 352-9580, 3529580, 452-9580, 4529580, AS-8434, AS8434, S-20127, S20127, W01-358-9580, W013589580, 9580, 1R13-118, 1R13118, AB1R13118, 10 10-21 P 434, 101021P434, 64394, 1R13-247
Weight
20.00
- Attribute Value
- Product Name AB-1R13-118
- Top Plate Bolt Hole Quantity 1
- Bottom Plate Bolt Hole Quantity 4
- Top Plate Diameter 10.3 in
- Bottom Plate Diameter 10.2 in
- Piston Material Plastic
- Minimum Height 7.2 in
- Maximum Height 23.5 in
- Top Plate Center To Center Diameter 0 in
- Bottom Plate Center To Center Diameter 5.66 in
- Bottom Plate Alignment Parallel
- Bracket No
- Bumper Yes
- Bellows Number 566-26-3-039, 566-26-3-068, 566-26-3-144
- Bellows Color Black
- Bellows Material Textile Reinforced Polymer Rubber
- Air Spring Type Rolling Lobe
- Make Hendrickson, Navistar/International
- Company Sku
- Automann AB1DK25C-9580
- Automann Bellows 1DK25C
- Continental 64394
- Continental Bellows 10 10-21
- Dayton 352-9580, 452-9580
- Firestone W01-358-9580, W01-358-9262
- Firestone Bellows 1T17CL9.5, 1T15VLT10.5, 1T15V11
- Flagg/Triangle AS-8434
- Flagg/Triangle Bellows 6386/94
- Goodyear 1R13-118
- Goodyear Bellows 566-26-3-039, 566-26-3-068, 566-26-3-144
- Infinity SR9580-P, SR9580-S
